White Laser Lighting
IR850-V
IR850-V
Regular price
$200.00
Regular price
$160.00
Sale price
$200.00
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
1-IR Module Product Specifications:
Wavelength=850nm±10nm
Laser type=VCSEL
Operating current=0.7A±0.2A
Operating voltage=DC12V±10%
Overall power consumption≤11W
Working Temperature=-35℃～+70℃
Dimension=64*27.4*40.6 mm（L*W*H）
2-Optical Performance:
Electric synchronous zoom, continuously adjustable from 2.0° to 70°, compatible with all
20X and 30X cameras available on the market.
Narrow-angle 2.0°: Effective Distance ≥500m, Spot Diameter 17.5m
Wide-angle 70°: Effective Distance ≥40m, Spot Diameter 56m
Optical output power=2.0±0.3W
3-Safety:
Class 3B(FDA、IEC)
Safety distance=9m@minimum beam angle
4-Communication mode:
RS-485, TTL serial port, manual control optional (Default: 9600bps)
Protocol=Pelco D
